Ruijie RG-EG209GS Reyee 9-Port Gigabit Cloud Managed SFP Router

Here are the detailed specifications for the RG‑EG209GS—a 9‑port Gigabit cloud‑managed router with SFP, suitable for offices, hotels, schools, CCTV systems, and more:

🔌 Physical Interfaces

• RJ45 Ethernet Ports (8 total):
  • 1 × fixed WAN
  • 7 × fixed LAN
  • Up to 3 of the LAN ports interchangeable as WAN, supporting up to 4 WAN links
• SFP Slot (1 Gb/s): Can be configured as LAN or WAN for fiber connectivity

⚙️ Performance & Hardware

• Processor: Dual-core 880 MHz
• Memory: 256 MB DDRIII RAM, 32 MB SPI flash
• Throughput:
  • Up to 600 Mbps (NAT + flow audit)
  • ~430 Mbps with full services (NAT + authentication, DPI, flow control)
• Concurrent Users: Supports up to 200 clients

🌐 Networking Features

• Multi‑WAN: Load balancing and failover with up to 4 WAN ports
• Routing: PPPoE client/server, DHCP, static IP
• VLAN: Supports up to 8 VLANs; IPv6, IPTV support
• QoS & Traffic Control: Smart flow control, user/app-based limits, diagnosis, real-time auditing

🔐 Security & VPN

• VPN Protocols Supported: IPsec, L2TP, PPTP, OpenVPN
  • Max tunnels: 8 IPsec, 8 L2TP, 16 OpenVPN
  • Approx. VPN throughput: IPsec 28 Mbps, L2TP 190 Mbps, OpenVPN 20 Mbps
• Firewall & Protection: ACLs, anti-flood, port-scan, SYN/Smurf/Land/Teardrop/ping‑of‑death mitigation
• Captive Portal & Authentication: WiFiDog, vouchers, SMS, QR code, portal/password login

☁️ Management & Cloud

• Cloud management via Ruijie Cloud & Reyee App; zero‑touch auto-setup
• Scalable control: As a gateway, can manage up to 150 APs/NBS + 128 switches; in AC mode up to 500 APs + 128 switches
• Portal customization: WYSIWYG captive portal pages

🛠️ Physical & Environmental

• Form Factor: Desktop (wall-mountable), fanless, compact
• Dimensions: 202 × 108 × 28 mm
• Weight: ~0.5 kg
• Power: 12 V / 1.5 A DC; consumption ≤ 18 W
• Operating Conditions: 0–40 °C; humidity 10–90% non-condensing; IP20; surge protection (~4 kV)
• Certifications: CE, RoHS, 3‑year warranty

✅ Summary

The RG‑EG209GS is a versatile, cost-effective cloud-managed router featuring 8 GigE ports, 1 SFP, and expandable 4-WAN support. With robust throughput (~600 Mbps), solid VPN, firewall protection, QoS, captive portal, and the ability to serve up to 200 users, it’s an excellent solution for SMBs, retail, education, and surveillance deployments.
