Ruijie Reyee RG‑RAP6262 -AX3000 Outdoor Omni-directional AP
- Wi-Fi 6 (AX3000) – Speeds up to 2.976 Gbps (2×2 MU-MIMO)
- Omni-Directional Antennas – Wide coverage, up to 300 m @5 GHz
- Dual Uplink Ports – 1× 1G PoE+ + 1× 1G SFP port
- Rugged Design – IP68-rated, operates –30°C to +65°C
- High Capacity – Supports up to 512 clients (recommended ~110)
- Power – IEEE 802.3at PoE+ or optional DC input (≤24 W)
- Mesh Ready – Reyee SON (Self-Organizing Network), Layer 3 roaming
- Security – WPA/WPA2-PSK, SSID hiding, VLAN, MAC filtering
- Smart Management – Cloud, app, or web GUI
- Ideal for: Schools, parks, estates, and public Wi-Fi zones
Here are the detailed specifications for the RG‑RAP6262 Reyee AX3000 High‑Performance Outdoor Omni‑Directional Access Point:
📶 Wireless Performance
- Wi‑Fi Standard: 802.11ax (Wi‑Fi 6), dual-band, 2×2 MU-MIMO
- Max Throughput: Up to 2.976 Gbps total (~574 Mbps @2.4 GHz + ~2402 Mbps @5 GHz) with OFDMA, 1024-QAM, and 160 MHz channels
🛰 Antennas & Coverage
- Omni-directional internal antennas
- Gain: ~3 dBi @2.4 GHz, 4 dBi @5 GHz
- Coverage radius: Field tested up to ~100 m on 2.4 GHz and ~300 m on 5 GHz
🌤 Durability & Form Factor
- Ingress Rating: IP68—fully sealed, waterproof, dustproof, flame-retardant, wind-resistant
- Operating Temp: –30 °C to +65 °C
- Surge Protection: 4 kV on ports
- Dimensions: ~230 × 230 × 195 mm (without mount)
- Weight: ~1.2–1.4 kg (without mount)
🔌 Ports & Power
- Ethernet: 1× 1 GbE PoE+ IN, 1× 1 GbE SFP
- DC Input: Optional 12 V/2 A DC jack
- Power Draw: ≤24 W
👥 Capacity & Coverage
- Client Capacity: Supports up to 512 clients (recommended ≤110–130 active)
- SSID Support: Up to 8 SSIDs
🔄 Advanced Features
- Mesh Networking: Reyee Self‑Organizing Network (SON) for seamless multi-AP deployment
- Roaming: Layer 2 & Layer 3 client roaming
- OFDMA, Beamforming, 160 MHz channels, DFS support
- Security: WPA/WPA2-PSK, blacklist/whitelist, SSID hiding, client isolation, VLAN support
🛠 Management & System
- Management: Free cloud portal, Reyee mobile app, and local web GUI
- Cloud Features: Auto RF optimization, topology monitoring, scheduled restarts, dual-bin firmware
✅ Summary
The RG‑RAP6262 delivers AX3000 performance (~3 Gbps) with omni-directional coverage, IP68 durability, and robust outdoor deployment capabilities. With both PoE+ and SFP uplinks, high client support, advanced Wi‑Fi 6 features, and seamless mesh capability, it’s perfect for campuses, parks, and large outdoor spaces.
