TP-Link AC1300 Whole Home Mesh Wi-Fi System – TL-DECO M5-3 (3-Pack)

The TP-Link AC1300 Whole Home Mesh Wi-Fi System – TL-DECO M5-3 (3-Pack) is a powerful whole-home mesh Wi-Fi solution engineered to replace traditional routers and range extenders with a single, unified network. Leveraging 802.11ac Wave 2 dual-band technology, the Deco M5 delivers a total combined speed of AC1300 (867 Mbps on 5 GHz + 400 Mbps on 2.4 GHz), ensuring lag-free gaming, smooth 4K streaming, and fast downloads.

Designed to blanket up to 5,500 sq. ft. with consistent Wi-Fi, this mesh system uses intelligent routing to automatically connect devices to the strongest node for uninterrupted connectivity. Built-in TP-Link HomeCare™ powered by Trend Micro adds enterprise-grade security, advanced parental controls, and device prioritization (QoS).

Detailed Technical Specifications

Wi-Fi Standards

• IEEE 802.11ac/n/a 5 GHz
• IEEE 802.11b/g/n 2.4 GHz

Performance & Speeds

• 5 GHz Band: 867 Mbps
• 2.4 GHz Band: 400 Mbps
• Total AC Speed: 1267 Mbps (marketed as AC1300)
• MU-MIMO: Yes (supports simultaneous data streams to multiple devices)
• Beamforming: Yes (directs Wi-Fi signal toward active devices for stronger performance)

Coverage & Mesh Capabilities

• Coverage: Up to 5,500 sq. ft. (3 units)
• Mesh Technology: TP-Link Mesh with adaptive path selection and self-healing network
• Roaming: Seamless roaming with a single SSID across all Deco units
• Number of Deco Units Supported: Up to 10 units in one network

Hardware Specifications

• Processor: Qualcomm IPQ4019 Quad-Core CPU @ 717 MHz
• Memory: 256 MB RAM
• Flash Storage: 32 MB
• Antennas: 4 internal omnidirectional antennas per unit
• Ethernet Ports: 2× Gigabit Ethernet (WAN/LAN auto-sensing) per unit
• Buttons: 1× Reset button
• Power Supply: 12V/1.2A per unit
• Dimensions: 120 mm × 38 mm (diameter × height)

Security & Software Features

• Encryption: WPA2-PSK (AES)
• Firewall: SPI Firewall
• HomeCare™ Security Suite:
  • Built-in Antivirus (Trend Micro)
  • Intrusion Prevention System (IPS)
  • Malicious Site Blocking
• Parental Controls:
  • User profile creation
  • Website filtering by category
  • Time limits & usage scheduling
• QoS (Quality of Service): Device & application prioritization

Smart Features & Management

• App Management: Deco App (iOS & Android) for setup, monitoring, and remote management
• Voice Control: Works with Amazon Alexa
• Automation: Supports IFTTT integrations
• Guest Network: Separate Wi-Fi access for visitors
• Firmware Updates: Automatic updates to maintain security and performance

Environmental Parameters

• Operating Temperature: 0°C – 40°C (32°F – 104°F)
• Storage Temperature: -40°C – 70°C (-40°F – 158°F)
• Operating Humidity: 10% – 90% RH (non-condensing)
• Storage Humidity: 5% – 90% RH (non-condensing)

Key Features

• Whole-home mesh coverage up to 5,500 sq. ft.
• AC1300 dual-band Wi-Fi for HD streaming and gaming
• Qualcomm quad-core processor for stable performance
• TP-Link HomeCare™ with antivirus, parental controls, and QoS
• Seamless roaming with one network name
• Easy app-based setup and management

Meta Description

TP-Link AC1300 Whole Home Mesh Wi-Fi System – TL-DECO M5-3 (3-Pack) delivers up to 5,500 sq. ft. mesh Wi-Fi coverage with AC1300 dual-band speeds, quad-core performance, TP-Link HomeCare™ security, parental controls, and seamless roaming for a reliable whole-home internet experience.
