HPE Aruba Networking CX 6410 v2 Switch

The HPE Aruba Networking CX 6410 v2 Switch is a next-generation modular chassis designed for enterprise core and aggregation networks. It delivers massive scalability, flexible port options (1G to 100G), advanced redundancy, and automation capabilities powered by Aruba’s AOS-CX operating system, ensuring high performance and reliability for data-intensive environments.

Detailed Specifications

General & Chassis

• Model: Aruba CX 6410 v2 (R0X27C)
• Form Factor: Modular 12U rack-mount chassis
• Slot Configuration: Supports up to 10 I/O line card slots
• Supervisor Modules: Dual redundant management modules with quad-core ARM Cortex-A72 @ 1.8 GHz
• Memory: 16 GB DDR4 ECC RAM
• Storage: 32 GB eMMC Flash

Performance & Capacity

• Switching Capacity: Up to 28 Tbps
• Throughput: Up to 20 billion packets per second (Bpps)
• Latency: Sub-microsecond depending on module configuration
• Packet Buffer: Up to 32 MB (varies by line card)
• Fabric Architecture: Clos-based design for high efficiency and low latency

Ports, Modules & Interfaces

• Line Card Options: Supports 1 GbE, 10 GbE, 25 GbE, 40 GbE, and 100 GbE modules
• PoE Support: IEEE 802.3af/at/bt Class 4 and Class 6 PoE options depending on module
• Uplink Support: 40 GbE or 100 GbE uplinks
• Stacking: VSX (Virtual Switching Extension) for high availability

High Availability & Redundancy

• VSX Support: Enables active-active redundancy and non-stop forwarding
• Power Supplies: Redundant, hot-swappable PSUs
• Cooling: Hot-swappable fan trays with front-to-back or back-to-front airflow options
• Failover: Hitless software upgrades and control-plane redundancy

Software, Management & Features

• Operating System: Aruba AOS-CX
• Management Interfaces: CLI, REST API, Web GUI, Aruba Central, AirWave, SNMP v2/v3
• Advanced Features:
  • Dynamic Segmentation and role-based access
  • MACsec encryption on supported ports
  • Full Layer 3 routing (OSPF, BGP, VRF, EVPN, VXLAN)
  • Real-time analytics and NetEdit automation
  • Network analytics engine for telemetry and monitoring

Physical & Environmental

• Dimensions (H × W × D): Approx. 52.8 cm × 44.2 cm × 44.8 cm
• Weight: Up to 53 kg fully loaded
• Operating Temperature: 0 °C to 45 °C
• Humidity: 5% to 95% (non-condensing)

Key Features

• Modular 12U chassis with flexible 1G–100G line card support
• 28 Tbps switching capacity for high-performance networks
• Redundant and hot-swappable components for maximum uptime
• Comprehensive Layer 3 routing and advanced network automation
• Integrated telemetry and analytics for predictive network management

Meta Description

The HPE Aruba Networking CX 6410 v2 Switch is a modular enterprise-grade switch chassis offering 28 Tbps switching, multi-speed port options up to 100 GbE, advanced AOS-CX automation, and robust redundancy — ideal for large campus cores and data-center aggregation.
