Ubiquiti UniFi Standard 16 PoE Switch (USW-16-PoE)
- 16 × 1 GbE RJ45 ports, including 8 PoE+ ports (802.3af/at)
- 2 × 1 GbE SFP uplinks for fiber connectivity
- Total PoE budget of 42 W
- Layer 2 switching features: VLANs, QoS, LACP, IGMP snooping
- Silent, fanless design with 1.3″ touchscreen display
- 36 Gbps switching capacity, ~27 Mpps forwarding rate
- 1U rack-mountable with internal 60 W power supply
- Managed via UniFi Network Controller (v7.2.94+)
The UniFi USW-16-PoE is a silent, rack-mountable Layer 2 switch with 16 GbE ports, 8 PoE+ outputs, 2 SFP uplinks, a 42W PoE budget, touchscreen display, and full UniFi Controller support for seamless network management.
🛠️ UniFi USW‑16‑PoE – Detailed Specs
🔌 Ports & PoE
- 16× 1 GbE RJ45 ports, with 8 auto-sensing 802.3af/at PoE+ ports (up to 32 W per port)
- 2× 1 GbE SFP uplink ports for fiber connectivity
- Total PoE budget: 42 W
⚡ Performance
- Switching capacity: 36 Gbps
- Non‑blocking throughput: 18 Gbps
- Forwarding rate: ~27 Mpps
🔄 Layer 2 Features
- Supports 1,000 VLANs, LACP, STP/RSTP, QoS, IGMP snooping (advanced), jumbo frames, 802.1X, ACLs, port mirroring, storm control, voice VLAN, and LLDP‑MED
🧩 Hardware & Design
- 1.3″ touchscreen display, fanless (silent) design
- Rack-mountable (1U) chassis; dimensions: 442 × 200 × 44 mm; weight: 2.8 kg (without brackets)
🏋️ Power & Heat
- Internal 60 W AC/DC power supply
- Power draw (excluding PoE): 18 W; max 60 W (with full PoE)
- Heat output: ~61 BTU/hr
🌡️ Environmental & Compliance
- Operating temperature: –5 °C to 40 °C; humidity: 10–90% non-condensing
- Certifications: CE, FCC, IC, Anatel; NDAA compliant
🧠 Management
- Managed via UniFi Network Controller (v7.2.94+ / v8+)
📊 Quick Specs Overview
| Feature | Specification |
|---|---|
| Ethernet Ports | 16 × 1 GbE RJ45 (8 PoE+) + 2 × 1 GbE SFP |
| Total PoE Budget | 42 W |
| Switching | 36 Gbps / 18 Gbps throughput / ~27 Mpps forwarding |
| Layer 2 Support | VLANs, QoS, LACP, STP/RSTP, IGMP, jumbo frames, ACLs |
| Display & Cooling | 1.3″ touchscreen; fanless, silent design |
| Form Factor | 1U rack or desktop; 442×200×44 mm; ~2.8 kg |
| Power Supply | Internal 60 W AC/DC; max power 60 W |
| Environment | –5 °C to 40 °C; 10–90% RH; NDAA compliant |
| Controller Support | UniFi Network Controller v7.2.94+ |
| Brand | Ubiquiti |
|---|
