Ubiquiti UniFi Gateway Pro (UXG‑Pro)
- Dual WAN: 1× 1GbE RJ45 + 1× 10GbE SFP+ (load balancing & failover)
- Dual LAN: 1× 1GbE RJ45 + 1× 10GbE SFP+
- Advanced Security: IDS/IPS (~3.5 Gbps), DPI, L7 firewall, VPN (IPsec, OpenVPN, WireGuard)
- Performance: Quad-core ARM Cortex-A57 CPU, 2GB DDR4 RAM
- Management: UniFi Network app, 1.3″ status touchscreen
- Power Redundancy: Built-in PSU + UniFi SmartPower RPS support
- Form Factor: 1U rack-mountable
- NDAA-compliant: Approved for government use
The UniFi Gateway Pro (UXG-Pro) is a high-performance enterprise router featuring dual WAN/LAN ports, advanced security with IDS/IPS, VPN support, and UniFi Network management—perfect for scalable, secure network deployments.
Here are the detailed specifications for the UniFi Next‑Generation Gateway Pro (UXG‑Pro):
🛠️ Hardware & Mechanical
- Dimensions: 442.4 × 43.7 × 285.6 mm (17.42″ × 1.72″ × 11.24″)
- Weight: 3.42 kg (7.54 lb)
- Enclosure: CNC-machined aluminum front; SGCC steel top/base
🧠 System & Performance
- CPU: Quad‑core ARM® Cortex®‑A57 @ 1.7 GHz
- RAM: 2 GB DDR4
🔌 Interfaces
- WAN
- (1) 1 GbE RJ45
- (1) 10 GbE SFP+ (supports multi‑WAN/failover)
- LAN
- (1) 1 GbE RJ45
- (1) 10 GbE SFP+
- Management: Dedicated Ethernet management port
- Display: 1.3″ touchscreen for status, boot/FW info
- Button: Single factory‑reset button
⚡ Power
- AC Power (internal supply):
- USA: 125 V AC @ 2.7 A, 60 Hz
- Worldwide: 200–240 V AC @ 1.7 A, 50/60 Hz
- DC Input: Compatible with RPS units (11.5 V DC @ 2.87 A)
- Max Power Consumption: 30 W (supply rated 50 W)
- ESD Protection: ±15 kV air discharge, ±8 kV contact
🌡️ Environmental
- Operating Temp: –10 °C to 40 °C (14–104 °F)
- Humidity: 5%–95% non‑condensing
⚙️ Networking & Security Features
- IDS/IPS Throughput: ~3.5 Gbps
- Security Features:
- Stateful & Layer‑7 (application) firewall
- Deep Packet Inspection (DPI)
- Intrusion Detection & Prevention (IDS/IPS)
- Content/ad blocking & zone‑based rules
- VPN / SD‑WAN:
- License‑free SD‑WAN
- Site‑to‑Site VPN (IPsec, OpenVPN, WireGuard, L2TP)
- Teleport zero‑config VPN
- Routing / QoS:
- Multi‑WAN load balancing & failover
- OSPF routing
- Advanced QoS, NAT (SNAT/DNAT/1‑to‑1), integrated RADIUS (w/ TLS)
- Other: LTE backup readiness, internet quality/outage reporting
🧩 Integration & Management
- Fully managed via UniFi Network (v8.3.32+, formerly v5.x+)
- Compatible with Cloud Key Gen2 Plus or UniFi Network Server
- Supports UniFi Power Backup and SmartPower outlet
- Rack-mountable (1U)
- Certifications: CE, FCC, IC; NDAA‑compliant
✅ Summary Table
| Feature | Specification |
|---|---|
| CPU/RAM | Quad‑core A57 @1.7 GHz / 2 GB DDR4 |
| Ports | 1×1 GbE + 1×10 GbE SFP+ per WAN/LAN |
| Throughput | ~3.5 Gbps DPI/IPS |
| Management | UniFi Network app, touchscreen |
| Power | Supports RPS backup, 30 W max |
| Security | DPI, IDS/IPS, firewall, VPN, QoS |
| Form Factor | 1U rack‑mount |
| Brand | Ubiquiti |
|---|
