The Ubiquiti UISP Router Pro 10 GbE Gateway (UISP‑R‑Pro) is a powerful 10 GbE gateway designed for high-performance ISP networks. Featuring a quad-core ARM CPU, 4 GB RAM, 8× Gigabit LAN ports, 4× 10G SFP+ uplinks, and a built-in touchscreen for easy monitoring, it delivers robust Layer 3 routing, traffic shaping, and remote management via the UISP platform—perfect for scalable, reliable deployments.

🔧 Detailed Specifications – Ubiquiti UISP‑R‑Pro (UISP Router Pro)

⚙️ Mechanical & Build

• Dimensions: 442.4 × 200 × 43.7 mm (1U rack-mountable)
• Weight: Approximately 3.3 kg
• Enclosure: Rugged SGCC steel, polycarbonate/ABS chassis

🧠 Processor, Memory & Storage

• CPU: Quad-core ARM Cortex-A57 @ 1.7 GHz
• RAM: 4 GB DDR4
• Flash: 16 GB eMMC

🌐 Ubiquiti UISP Router Pro 10 GbE Networking Interfaces

• LAN: 8 × Gigabit RJ45 ports
• WAN: 1 × Gigabit RJ45 uplink port
• Uplinks: 4 × 1/10 Gbps SFP+ ports
• Management: In-band Ethernet, Bluetooth setup
• Display: 1.3″ touchscreen LCD for status and configuration

🔌 Power & Protection

• Power Input: Internal AC/DC (100–240 V AC, 1.5 A) plus optional 27 V DC input (2.2 A)
• PSU: 60 W internal supply; maximum power draw ~50 W
• ESD/EMP: Air ±15 kV, Contact ±8 kV protection

🌡 Environment & Certs

• Temperature Range: –10 °C to +50 °C
• Humidity: 5–95% non-condensing
• Certifications: CE, FCC, IC; NDAA‑compliant

💡 LEDs & Indicators

• RJ45 and SFP+ ports have speed/link/activity LEDs
• Status and touchscreen for real-time device info

🛠 Software & Management

• Managed by UISP App (v1.4.5+)
• Features: Layer 2 switching on ports 1–8, firewall, NAT, OSPF routing, traffic shaping, VLANs, remote monitoring
• Fully rack-mountable 1U form factor with touchscreen management

🔹 Key Highlights

• Heavy-duty 10 GbE router with 8 gigabit LAN and 4 SFP+ uplinks
• Quad-core Cortex-A57 CPU and 4 GB memory for high-performance networking
• Internal 60 W PSU with optional DC input and strong protection
• Built-in touchscreen and BLE for local configuration and status checks
• Ideal for ISP backend, micro-POPs, and UISP-managed networks

✅ Meta Description

The Ubiquiti UISP Router Pro 10 GbE is a rack-mountable 10 GbE ISP gateway featuring 8× Gigabit LAN, 4× SFP+ uplinks, quad-core processor, touchscreen UI, and advanced UISP routing—built for performance and scalability.
