The Tycon POE‑EXT‑GD‑HP is a rugged, high-power Gigabit PoE extender designed to overcome the 100-meter Ethernet cable limitation. It operates fully passively, powered by PoE (active or passive), regenerating both power and data to allow long-distance PoE deployments. Ideal for IP cameras, outdoor wireless radios, VoIP systems, and industrial networks, this device is built with a weatherproof enclosure for harsh outdoor environments.

⚡ Electrical Specifications

• PoE Input Voltage: 44 to 57 VDC (passive or IEEE 802.3af/at compliant)
• PoE Input Mode:
  • Mode A (Pins 1,2 = positive; Pins 3,6 = negative)
  • Mode B (Pins 4,5 = positive; Pins 7,8 = negative)
• PoE Output Voltage: Equal to input voltage, minus internal drop (typically ~1–2 V)
• PoE Output Power: Up to 25 W (IEEE 802.3at Class 4)
• Power Consumption: ~2 W typical
• Data Rate: 10/100/1000 Mbps (Gigabit Ethernet supported)
• Ethernet Ports: Two shielded RJ45 ports (Input and Output)
• PoE Regeneration: Re-injects PoE to power downstream devices
• Max Cable Extension: Adds an extra 100 m per unit; up to 300 m with multiple units
• Auto Negotiation: Supports auto speed, duplex, and MDI/MDI-X crossover

🏗 Mechanical & Physical Specifications

• Enclosure: IP66-rated weatherproof aluminum housing
• Mounting: Integrated mounting flange for pole or wall mount
• Dimensions: 185 mm x 45 mm x 45 mm (7.3 in x 1.8 in x 1.8 in)
• Weight: ~240 grams (8.5 oz)
• Cable Type Supported: CAT5e or higher, shielded recommended for outdoor use

🌡 Environmental Ratings

• Operating Temperature: –25 °C to +55 °C (–13 °F to +131 °F)
• Storage Temperature: –40 °C to +85 °C
• Operating Humidity: 0% to 100% (non-condensing)
• Weather Resistance: Fully sealed for outdoor applications (dust, rain, humidity)

🛡 Protections, Compliance & Reliability

• Built-in Surge Protection: For both data and power lines
• Certifications: RoHS Compliant, IEEE 802.3af/at standards
• Product Lifespan: Designed for long-term deployment in harsh conditions
• Warranty: 2-year limited manufacturer warranty

🧰 Typical Applications

• Extending PoE to wireless access points on rooftops or towers
• Surveillance systems with remote IP cameras
• Industrial control networks with remote sensors and actuators
• Outdoor PoE lighting or smart city infrastructure
• Remote VoIP phones or access control systems

Meta Description:

Tycon POE‑EXT‑GD‑HP Gigabit PoE Extender adds 100 m per unit to Ethernet and PoE lines. Powered by 802.3af/at or passive PoE, it supports up to 25 W output, features IP66 weatherproof housing, and is ideal for outdoor cameras, wireless gear, and industrial networks.
