TP-Link 300Mbps Wireless N Outdoor Access Point – EAP110-Outdoor

The TP-Link 300Mbps Wireless N Outdoor Access Point – EAP110-Outdoor is a weatherproof N300 wireless outdoor access point designed for long-range Wi-Fi coverage in parks, schools, farms, and outdoor event areas. Featuring passive PoE support, multiple operational modes, and centralized Omada SDN management, it delivers stable, extended wireless connectivity in harsh outdoor conditions.

Detailed Specifications

Wi-Fi Standards:

• IEEE 802.11b/g/n
• 2.4 GHz single band

Speed Performance:

• Up to 300 Mbps at 2.4 GHz

Frequency Bands:

• 2.4 GHz only

Antenna Design:

• 2× 5 dBi detachable omnidirectional antennas
• Outdoor-optimized coverage with strong penetration

Operation Modes:

• Access Point Mode
• Multi-SSID Mode

Ports:

• 1× 10/100 Mbps Ethernet Port (supports passive PoE)

Coverage & Capacity:

• Up to 200 meters+ coverage in open areas
• High transmission power (up to 27 dBm) for long-range Wi-Fi
• Supports up to 8 SSIDs

Security:

• WPA/WPA2-Enterprise encryption
• Captive portal for guest authentication
• Access control and MAC filtering

Management Features:

• Omada SDN cloud and local controller support
• Web UI and Omada app management
• VLAN support for network segmentation

Durability:

• Weatherproof enclosure with IP65 rating
• Lightning protection: 6 kV
• ESD protection: 15 kV

Power Supply:

• Passive PoE (up to 60 meters) for flexible installation
• Includes passive PoE adapter

Mounting Options:

• Pole or wall mount (mounting kit included)

Dimensions:

• 8.2 × 3.4 × 1.9 in (209 × 94 × 51 mm)

Key Features

• Outdoor N300 wireless access point with 2.4 GHz coverage
• Up to 200+ meters range with high-power transmission
• IP65 weatherproof casing for harsh environments
• Supports Omada SDN for centralized management
• Passive PoE for flexible deployment

Meta Description

TP-Link 300Mbps Wireless N Outdoor Access Point – EAP110-Outdoor N300 long-range outdoor access point with IP65 weatherproof casing, passive PoE, Omada SDN management, and up to 200+ meters coverage.
