MikroTik RBSXTG‑5HPacD‑SA – SXTsq 5ac Wide Sector Outdoor CPE

The MikroTik RBSXTG‑5HPacD‑SA – SXTsq 5ac Wide Sector Outdoor CPE, is a rugged outdoor wireless CPE/access point featuring a 90° sector antenna, built-in Gigabit Ethernet, and a compact fanless design. It’s perfect for point-to-multipoint base stations in outdoor environments.

General & Hardware

• CPU: Single-core QCA9557 @ 720 MHz (MIPS architecture)
• Memory & Storage: 128 MB RAM, 128 MB NAND flash
• Operating System: RouterOS with License Level 4
• MTBF & Temperature Range: ~200,000 hours; –40 °C to +70 °C
• Enclosure Rating: IP54, passive (fanless) cooling

Wireless

• Frequency: 5 GHz only (802.11a/n/ac)
• Throughput: Up to 867 Mbps with 256-QAM over 80 MHz channels
• Antenna: Integrated 14 dBi, dual-polarized 90° sector antenna
• Chains: 2×2 MIMO using QCA9892 chipset
• Protocols: Supports Nstreme, Nv2 TDMA, and IPsec hardware offload

Interfaces & Power

• Ethernet: 1 × Gigabit RJ45 port with Auto MDI/X
• PoE: Supports 802.3af/at passive PoE (12–57 V), max 12 W consumption
• USB: 1 × USB-A 2.0 port (max 1 A)

Monitoring & Features

• Sensors: PCB temperature and voltage sensors
• Beeper: Included for alerts
• LEDs: Power, Ethernet, and signal indication
• Build: Pole-mountable with hose clamp and grounding support

Meta Description

MikroTik RBSXTG‑5HPacD‑SA (SXT SA5 ac) is a rugged outdoor 5 GHz CPE with integrated 14 dBi 90° sector antenna, 867 Mbps 802.11ac performance, Gigabit Ethernet with passive PoE, USB, and RouterOS L4—ideal for point-to-multipoint wireless deployments.
