The Lenovo ThinkSystem ST250 V3 Tower Server is a powerful and versatile single-socket tower server designed for growing businesses, branch offices, and remote sites. With support for Intel Xeon E-2400 Series processors, up to 128GB of DDR5 ECC memory, enterprise RAID controllers, and hot-swap storage, it provides robust performance, reliability, and scalability. Its XClarity Controller 2 (XCC2) Platinum ensures enterprise-grade system management and monitoring.

---

Lenovo ST250 V3 (Part Number: 7DCEA02WEA)

Processor

• Intel Xeon E-2436
• 6 cores / 12 threads
• Base clock: 2.9 GHz
• Cache: 12 MB Intel Smart Cache
• TDP: 65W
• Supports PCIe Gen5 lanes

Memory

• Installed: 1x32GB DDR5 ECC UDIMM
• Speed: Up to 4400 MT/s
• Slots: 4 DIMM slots
• Maximum supported: 128GB DDR5 ECC UDIMM

Storage

• Drive Bays: Up to 8x 2.5″ Hot-Swap bays
• Installed: Empty by default (flexible configuration)

RAID / Storage Controller

• Lenovo ThinkSystem 5350-8i RAID Controller
• PCIe Gen4, 12Gbps SAS / SATA support
• RAID Levels: 0, 1, 5, 6, 10, 50, 60
• Cache and flash-backed write protection for data safety

Networking

• Onboard Ethernet (O/B Gigabit LAN standard)
• Supports optional higher-speed NICs

Expansion Slots

• PCIe Gen5 and Gen4 slots available for GPU, NIC, or storage expansion

Power Supply

• 800W Hot-Swap Titanium-rated PSU (96% efficiency)

Management

• XClarity Controller 2 (XCC2) Platinum standard
• Advanced out-of-band management, remote monitoring, and diagnostics

Other Features

• No DVD drive
• Tower form factor
• Enterprise reliability features: hot-swap PSU, hot-swap storage, redundant design options

Warranty

• 3 Years

---

Lenovo ST250 V3 (Part Number: 7DCEA02VEA)

Processor

• Intel Xeon E-2468
• 8 cores / 16 threads
• Base clock: 2.6 GHz
• Cache: 16 MB Intel Smart Cache
• TDP: 65W
• PCIe Gen5 ready for expansion cards

Memory

• Installed: 1x32GB DDR5 ECC UDIMM
• Speed: 4400 MT/s
• 4 DIMM slots total
• Expandable up to 128GB DDR5 ECC

Storage

• Drive Bays: Supports up to 8x 2.5″ Hot-Swap bays
• Configurable with enterprise HDDs or SSDs

RAID / Storage Controller

• Lenovo ThinkSystem 5350-8i RAID controller
• 12Gbps SAS / SATA support
• RAID Levels: 0, 1, 5, 6, 10, 50, 60

Networking

• Onboard Gigabit Ethernet (standard)
• Supports optional 10GbE or faster NICs

Expansion Slots

• Multiple PCIe Gen5/Gen4 slots for networking, accelerators, or storage expansion

Power Supply

• Hot-Swap 800W Titanium PSU (96% efficiency)

Management

• Lenovo XClarity Controller 2 (XCC2) Platinum
• Enterprise-class remote management and monitoring

Other Features

• No DVD drive
• Hot-swap storage design for easier maintenance and scalability

Warranty

• 3 Years

---

Key Features

• Powerful Intel Xeon E-2400 Series CPUs with 6-core and 8-core options.
• DDR5 ECC memory support, expandable up to 128GB.
• Up to 8x 2.5″ hot-swap bays for flexible SSD/HDD configuration.
• Enterprise-class Lenovo 5350-8i RAID controller with advanced RAID levels.
• 800W Titanium-rated hot-swap PSU for maximum energy efficiency.
• XClarity Controller 2 (XCC2) Platinum for advanced system management.
• Designed for SMBs and enterprises needing reliability, scalability, and low noise.

---

Meta Description

Lenovo ThinkSystem ST250 V3 tower servers with Xeon E-2436 (6-core) and Xeon E-2468 (8-core), DDR5 ECC memory, 8x 2.5″ hot-swap bays, 5350-8i RAID, 800W Titanium PSU, and XCC2 Platinum management. Scalable, efficient, and enterprise-ready.
