MikroTik CRS326‑24G‑2S+RM 10G rackmount switch is a silent, fanless rackmount smart switch with 24 Gigabit RJ45, 2× 10G SFP+ uplinks, dual-boot SwOS/RouterOS L5, VLAN/ACL features, and low 24 W power usage—great for labs and SMB environments.

Here are the detailed specifications for the MikroTik CRS326‑24G‑2S+RM 10G rackmount switch

🧠 Core Hardware

• Product Code: CRS326‑24G‑2S+RM
• CPU: Marvell 98DX3236A1 (ARM‑based), single core @ 800 MHz
• RAM: 512 MB DDR3
• Storage: 16 MB flash for firmware
• MTBF: ~200,000 hours at 25 °C

🔌 Ports & Connectivity

• Ethernet: 24 × 10/100/1000 Mbps RJ45
• Fiber/Uplink: 2 × SFP+ cages (compatible with 1.25 Gb SFP & 10 Gb SFP+)
• Console: 1 × RJ45 serial port

⚙️ Operating System & Licensing

• Dual-Boot: SwOS or RouterOS v7
• RouterOS License: Level 5

⚡ Power & Cooling

• Power Inputs:
  • DC jack (10–30 V)
  • Passive PoE-in (Ether1, 10–30 V)
• Max Power Consumption: ~24 W
• Cooling: Passive (fanless)

📶 Switching Performance

• Non-blocking Throughput: ~44 Gbps
• Max Packet Rate: ~65 kpps @ 64 B / ~3.6 kpps @ 1518 B
• MAC Table: 16,000 entries; VLAN support (up to 4,000)
• L2 Features: VLANs, port isolation, MAC filtering, mirroring, bandwidth control, ACL, STP, SNMP, neighbor discovery

🌡 Physical & Environmental

• Dimensions: 443 × 144 × 44 mm (1U rackmount)
• Operating Temp: –40 °C to +60 °C (tested)
• Certifications: CE, EAC, RoHS; IP20 (indoor)

📦 Included Accessories

• 24 V 1.2 A power adapter, rack ears, screws
